Products
Transformers
MEGALIGHT SAFETY isolated low voltage transformers are used as power supplies for the Megalight SAFETY -range lamps. They are robust but cleverly designed so they are easily moved. As default we equip the transformers with a double SELV outlet, so you can power up two lamps directly from the transformer. Most of the SAFETY -range lamps have also a socket on them for chaining, so one transformer can give power to several lamps.
We have stock models for 24VAC and 42VAC, with SELV outputs. Other voltages and output sockets are also available on request.
MEGALIGHT SAFETY Transformers can be equipped with the following alternative sockets:
A) CEE309 24VAC
A) CEE309 42VAC
B) SELV 24 or 42 VAC
MEGALIGHT SAFETY Transformers Technical details:
| MODEL | SUPPLY VOLTAGE | SECONDARY VOLTAGE | POWER (VA) | CAPACITY (24W lamps) | Dimensions (l * w * h) mm | Weight kg |
|---|---|---|---|---|---|---|
| KLMH100 | 230 VAC | 24 VAC | 100 VA | 3 pcs | 255 * 134 * 87 mm | 2 kg |
| KLMH200 | 230 VAC | 24 VAC | 200 VA | 6 pcs | 255 * 134 * 87 mm | 3,8 kg |
| KLM350 | 230 VAC | 42 VAC | 350 VA | 15 pcs | 255 * 134 * 87 mm | 4,5 kg |
